Our High-Strength Aluminium Wall Formwork sets a new standard in modern construction, offering unmatched efficiency, durability, and precision for demanding projects. Its core advantage stems from the premium aluminum alloy: delivering exceptional lightweight strength for easier handling and faster installation, combined with inherent corrosion resistance for a long service life.
This engineered material ensures superior stability, resisting warping through repeated uses to guarantee precise wall dimensions and smooth concrete finishes every time. It stands as the reliable, high-performance choice for a wide range of Reusable Aluminium Wall Formwork applications.
| Item | Specifications |
| Material | 6061-T6 aluminum alloy |
| Surface treatment | Powder coated |
| Weight | 23 kg/sqm |
| Panel height | 3000mm, 2500mm, 1500mm, 1250mm, 750mm |
| Panel width | 1000mm, 750mm, 500mm, 250mm |
| Panel depth | 117mm |
| Plywood thickness | 15mm |
| Allowable concrete pressure | 60 kN/m2 |
As a premium Lightweight Aluminium Wall Formwork, the appropriately sized panels allow highly efficient manual handling on site without the need for heavy tower cranes.
This engineered Modular Aluminium Wall Formwork utilizes a universal adjustable alignment clamp to enable quick, secure connections across all panels, significantly slashing overall installation time.
It flexibly adapts to both horizontal and vertical structural configurations, perfectly fitting various complex commercial and Residential Aluminium Wall Formwork designs.
The inherent engineering properties of this Corrosion-Resistant Aluminium Wall Formwork ensure maximum structural durability, enabling hundreds of repetitive reuses for long-term project cost savings.
As a key performance indicator of our advanced aluminium formwork system, it delivers a flawless, smooth concrete finish, drastically minimizing post-processing like plastering to cut material and labor overhead.
Rapid, precise assembly and structural disassembly reduce on-site labor dependencies and speed up construction schedules, making it the ideal High-Rise Building Aluminium Wall Formwork solution for fast-paced tower developments.
Modern monolithic concrete casting demands extreme structural integrity, tight dimensional tolerances, and rapid cycle times. Lianggong's advanced Aluminum Wall Formwork systems are engineered to meet these rigorous performance parameters, delivering unmatched precision and execution efficiency across a diverse range of structural topologies:
For repetitive multi-family housing developments, mass residential townships, and apartment complexes, our specialized residential aluminium wall formwork ensures rapid floor-to-floor cycles. The system facilitates simultaneous pouring of vertical walls and load-bearing components, producing architectural concrete surfaces with superior flatness that drastically cuts subsequent down-stream plastering overhead.
Large-scale office towers, retail podiums, and urban corporate complexes involve complex structural layouts and strict vertical alignment requirements. Implementing our high-capacity Commercial Aluminium Wall Formwork allows contractors to maintain rigid dimensional accuracy over hundreds of floor repetitions. This lightweight yet robust design optimizes crane utilization and streamlines logistics in demanding High-Rise Building Aluminium Wall Formwork deployments.
Underground forming work subjects construction equipment to severe hydrostatic pressure, limited working space and persistent damp environments. Our anti-corrosion aluminum wall formwork is the ideal solution for foundation casting, deep basement construction, retaining walls and utility tunnels. Boasting outstanding structural stiffness, it resists panel bending under strong lateral concrete pressure, delivering fully sealed joints and completely watertight integral structures.
